BlockStorageDeviceDriverKit grant confirmed by support but shows "No Requests" in the portal. How to resolve?

Code Signing Entitlements BlockStorageDeviceDriverKit Files and Storage SCSIControllerDriverKit DriverKit

Created Jul ’26

Replies 27

Boosts 1

Views 4.7k

Participants 4

Hello!

I am hoping a DTS engineer or someone who knows the Capability Requests portal can help, because I am stuck between a written support confirmation and what the portal actually shows.

Background. We are building a native macOS iSCSI initiator for SOHO and home NAS use, developed over close to two years. A userspace daemon runs the iSCSI protocol and a DriverKit system extension presents the remote LUN as a block device. The code is essentially complete. Only the DriverKit extension cannot be signed, loaded and validated without the entitlement.

We submitted request 32PC8MGU57 for two entitlements: com.apple.developer.driverkit.family.block-storage-device for the extension com.aviontex.iscsi.AviontexISCSI.AviontexInitiator com.apple.developer.driverkit.userclient-access for the app com.aviontex.iscsi.AviontexISCSI, scoped to the extension bundle id

The problem. On June 25 Developer Support confirmed in writing that both entitlements were granted. The portal does not match that: Block Storage Device: No Requests: on both App IDs UserClient Access: Assigned: on the app SCSI Controller: Submitted: on the app

So the one entitlement we actually need, Block Storage Device, shows as never requested, even though request 32PC8MGU57 covered it and support confirmed the grant. The case was escalated to the senior team on July 2 (case 102922935570). Follow-up emails since then have not received a response.

Why Block Storage Device specifically

Our initiator has no PCI or Thunderbolt bus and no DMA path, so SCSIControllerDriverKit does not fit. This is confirmed by DTS in thread 776020, where Kevin Elliott explains that SCSIControllerDriverKit passes data through fBufferIOVMAddr as a physical address with no mechanism to convert it into a VM address the dext can access. He also notes it cannot be used with any bus other than PCI or Thunderbolt. Block Storage Device is therefore the family we need.

My questions: Am I reading the portal correctly: Block Storage Device not requested, UserClient Access assigned, SCSI Controller submitted? From here, what is the correct way to get Block Storage Device onto these two App IDs, with both the Development and the Distribution grant, since our public beta depends on Distribution? Should I submit a new request through the Capability Requests tab or does the escalated case handle it? Is there any way to get visibility on the escalated case, since email follow-ups are not being answered?

A full technical justification is prepared and we are happy to share the source code. Any guidance would be appreciated.

Thank you.

Aviontex OP

Hi Kevin,

yes, I mean the initiator perspective, real iSCSI READ/WRITE over the network. Right now it is more annoying than technically critical. The important part is the DEXT does what it should, at least that is how it looks.

I completely agree with you. If WRITE runs but READ does not run cleanly, this is almost certainly a code issue, not a framework issue. My personal guess is that it comes down to a wrong or missing request ID, READs and WRITEs getting in each other's way during lookup. But that is only a theory. We will see who is right in the end. The bets are on. 😉

Nonetheless, thank you for your continued support so far. That is not something I take for granted. Thank you again!

I promise you, once it runs, you will be the first to know. I will send you valid numbers then. I am curious myself.

Best regards,

Torsten

Aviontex OP

Hi Kevin,

first off, thanks a lot for your pointers, and yes, macOS now has a DEXT-based iSCSI initiator for NAS. There's still a bit left to do, but the connection holds and traffic runs at full tilt. What more could you want. And as promised, here are some numbers:

Cache-independent RAW iSCSI measurements

These are cache-independent RAW whole-disk measurements against a real 4.29 TB NAS-backed iSCSI LUN, RAW and unformatted target. Every run completed deterministic read-back verification with zero data mismatches, so the VERIFY column is a full end-to-end integrity pass over the whole transfer.

Notes:

Host queue depth was 256 for every run. The two 5G tests used sixteen 1 MiB requests, so the effective queue depth there was 16.
Both 5G connections went straight to the NAS over independent mobile networks, no VPN. Throughput on those two rows is set by the radio path. What matters is that the initiator carries complete, read-back-verified iSCSI transfers over a live mobile link, the groundwork for our iSCSI-over-TLS layer in the initiator.
The 400 GiB endurance run stayed at 111.592 MiB/s WRITE and 111.537 MiB/s READ, WRITE, READ and VERIFY each about 61 minutes, with a bounded DEXT proxy count throughout and no port-table growth.

This is all running on Intel now, and running well on older Intel hardware specifically mattered to us: for something like this it has to stay performant on aging systems, not just the latest ones. From next week we move to Apple Silicon (M5 Pro) and see how throughput holds up there. The initiator itself is not fully done either, getting a DEXT driver cleanly embedded inside an application turned out to be a real challenge. If anything else turns up during beta testing, I'll post it here, though I doubt it will.

One last thing, and I mean it. Thanks for the past few weeks. You revisited your own conclusions the moment the facts moved, and you went out of your way more than once, the entitlement request on our behalf being the clearest example. That kind of engagement is rare and made this a real pleasure.

So thank you, Kevin. Enjoy your weekend, and until the next posting. :)

Torsten
